Xiaomi Mi AIoT AX3600 WiFi Router

< >

Xiaomi Mi AIoT AX3600 WiFi Router

  • NO.:ECS053582
  • Goods click count：743
  • Shop price:
  • Quantity：
  • Add to cart
Goods Brief:

Highlights

Qualcomm 6-Core Enterprise-Grade

Enterprise-level professional chip P08071A, equipped with Qualcomm 4-core 64 bit A53 CPU+2 core network acceleration engine.The professional chip runs more stable.

OFDMA

OFDMA significantly improves the transmission efficiency of multiple devices working at the same time and reduces the delay.

MU- MIMO

MU-MIMO allows multiple antennas of a router to serve multiple devices at the same time.

Support Beamforming Technology, Directional Enhanced Signal

Beamforming technology, which can automatically detect the position of mobile phones, computers and other terminals in the network, enhance the signal of the location, make Wi-Fi effective coverage wider, and the signal quality is more stable.

Xiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - BlackXiaomi AIoT Wireless Dual Band Router 2976 Mbps 2.4GHz + 5GHz WiFi High Gain 6 Antennas 512MB Memory - Black

Specification

General

Brand: Xiaomi
Model: AIoT
Type: Wifi Router
Color: Black

Specification

CPU: IPQ8071A 4Core A53 1GHz
Network Acceleration Engine: Dual core 1.7GHz NPU
ROM: 256MB
Memory: 512MB
2.4G Wi-Fi: 2x2 (IEEE802.11ax, 574Mbps)
5G Wi-Fi: 4x4 (IEEE802.11ax, 2402Mbps)
Antenna: 6 x External high gain antennas + 1 x AloT Antenna
Heat Dissipation: Natural heat dissipation
Physical Interface: 1 x 10/100/1000 WAN (Auto MDI/ MDIX);3 x 10/100/1000 LAN (Auto MDI/ MDIX)
LED Indicator Light:
1 x SYSTEM indicators
1 x INTERNET indicators
4 x Network ports
1 x AIoT light
Reset Button: 1 x Reset button
Power Input Interface: 1 x Power input interface
Wireless Standard: IEEE 802.11a/b/g/n/ac/ax, IEEE802.3/3u/3ab
Certification Standards: GB/T9254-2008; GB4943.1-2011
Dual Band: 2.4GHz, 5GHz
Wireless Channel: 2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13
5GHz Channel: 36,40,44,48,149,153,157,161,165
Modulation Mode: 11b: DSSS: DBPSK(1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)
11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM(24/36Mbps), 64QAM(48/54Mbps)
11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0~MCS15
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM.
Rate Set: MCS0~MCS9 (4 streams supported)
11ax: MIMI-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM. Rate set: MCS0~MCS11(4 streams supported)
Operating System: Intelligent router operating system MiWiFi ROM based on OpenWRT deep customization
Wireless Security: WPA-PSK / WPA2-PSK/ WPA3-SAE encryption, wireless access control (black and white list), hidden SSID, intelligent anti-scratch network
Management Application: Support Web, Android, iOS
Working Temperature: 0~40ºC
Storage Temperature: 10%~90%RH Non-condensing
Working Humidity: -40~70ºC
Storage Humidity: 5%~90%RH Non-condensing

Weight & SizeWeight: 0.5kg
Size (L x W x H): 41.0 x 13.4 x 17.7cm
Package Contents

1 x Xiaomi AIoT router AX3600
1 x Chinese user manual
1 x Power line (12V/1.5A)
1 x Network cable
